A Galton board walked by pedestrians

▶ https://www.youtube.com/shorts/ekbvCdy1P3w

The problem

The Galton board is the classic demonstration of the central limit theorem. Balls drop through staggered rows of pins, bounce left or right at every pin, and pile up at the bottom in a bell-shaped heap. Each ball performs a random walk, and the sum of many independent ±1 steps is approximately normally distributed.

Here the balls are pedestrians. 800 agents enter through a 1.2 m slit at the top of a 24 m × 34 m arena and walk through 10 staggered rows of pegs. At every row an agent flips a coin and takes the left or right gap below its current one. At the bottom, each column has its own exit, so the exit position records the outcome of 10 coin flips.

Result of the run in this repository:

quantity	value
agents arrived	681
mean exit position	12.0 m (board centre)
standard deviation	3.36 m
random-walk prediction	√10 · 1 m = 3.16 m

How the coin flip is modelled in JuPedSim

The interesting part is not the board, it is how a per-row random decision is expressed with JuPedSim's journey system. JuPedSim has no probabilistic transition, so the randomness lives in Python and JuPedSim does the walking.

1. One waypoint stage per gap. Every gap of every peg row that is reachable from the slit gets a waypoint stage at the gap centre with a 0.5 m radius: 2 gaps in the first row, 3 in the second, up to 11 in the last, plus a start waypoint above the first row.

2. Coin flips at spawn time. When an agent is created, numpy draws 10 values from {−1, +1} with equal probability. The cumulative sum of the first r+1 flips is the gap offset after row r, so the tuple is the agent's complete path.

3. The path becomes a journey. For that tuple the code builds a JourneyDescription whose stages are the start waypoint, the 10 chosen gap waypoints and the exit of the final column, with a fixed transition from each stage to the next. Journeys are cached by tuple, so identical paths share one journey.

4. One exit per column. JuPedSim steers towards the centroid of an exit polygon. A single wide exit pulled every agent back to the centre after the last row, so each column has its own 0.9 m exit bin.

5. JuPedSim does the rest. Routing takes the agent from waypoint to waypoint around the pegs, and the collision-free speed model handles queueing and interactions. The agent never decides anything during the run, so the probability is exactly 1/2 per row and the exit histogram is a true binomial(10, 1/2) sample. What the simulation adds is the physical walk, not the randomness.

Two alternatives were tried and rejected:

• Round-robin transitions inside JuPedSim, alternating left and right at each gap. That is a rotor-router: deterministic, far too regular, and the spread collapsed.
• No waypoints, just an exit. Shortest-path routing is deterministic, so every agent walked straight down the middle.

If the decision should live inside the simulation, the closest option is switch_agent_journey when an agent reaches a row, rolling the die there instead of at spawn.

Why JuPedSim

JuPedSim is an open-source pedestrian dynamics library. It provides the pieces this demo needs out of the box:

• a walkable area with obstacles (the pegs) and automatic routing around them,
• journeys built from waypoint stages with explicit transitions,
• operational models that keep agents from overlapping, so the stream really does split and queue at the pegs like balls on pins,
• a trajectory file that the JuPedSim web app loads directly to play back the simulation with a density heatmap.

Files

• galton.py: builds the geometry, runs the simulation, writes galton.sqlite, arrivals.npy and the histogram galton_hist.png.
• render.py: renders galton.sqlite as an mp4 with a cumulative occupancy heatmap.
• video/: the Remotion project for the published video (title card, screen recording from the web app, animated histogram, thumbnail).

Run

python -m venv .venv && .venv/bin/pip install -r requirements.txt
.venv/bin/python galton.py      # simulation + histogram
.venv/bin/python render.py      # optional: heatmap video from the sqlite file

Open galton.sqlite in https://app.jupedsim.org to play it back interactively.

To rebuild the published video:

cd video && npm install
npm run render                          # video/out/galton_final.mp4
npx remotion still src/index.ts Thumb out/thumbnail.png

The Remotion project expects video/public/sim.mp4, a screen recording of the web-app playback of galton.sqlite. It is not in the repository; the finished result is on YouTube. Record your own and drop it in, or adjust VIDEO_S in video/src/Galton.tsx to its length. video/src/hist.json holds the exit-bin counts exported from arrivals.npy.

Credits and license

Code: MIT, see LICENSE.

Galton board photo in the video and thumbnail: Matemateca (IME/USP), photo by Rodrigo Argenton, CC BY-SA 4.0, via Wikimedia Commons. Galton's 1889 quincunx drawing (video/public/galton_1889.png) is in the public domain.
